QS165 35H V2 MOTOR QSD165B-35 for Surron Light Bee Conversion

Original price was: $307.69.Current price is: $276.92.

Official Price:$607.69/pcs
N.W.:8.0kgs
G.W.:8.4kgs
Dimension:34cm*34cm*43cm
Production Period:10~12 working days


QS165 35H V2 MOTOR QSD165B-35 5000W Encoder PMSM Mid drive Motor for Surron Light Bee Conversion

For QS-165-5KW-V2 mid drive motor, it could be used for electric light motorcycle, which could be 72V@90KPH.

  • Application: e.g. Similar light bee
  • E-motorcycle weight: approx 80kg+1*70kg
  • Speed: continuous 90km/h
  • Gear ratio: 1:4.77 (single steps transmission )
  • Climbing slope: 20°@10kph @150kg@60s
  • Battery: 72V40ah lithium
  • Tire: 100/70-19

  If you have interested in this product, you can contact with our sales directly.

  Sales Contact: damon@siaecosys.com

  Skype: Damon Wong(QSMOTOR)

 What’s App/We Chat: +86 18758618893

Aliexpress online purchasing link for this motor:(Click the photo for hyperlink)

QS165 35H V2 MOTOR QSD165B-35 for Surron Light Bee Conversion
QS165 35H V2 MOTOR QSD165B-35 for Surron Light Bee Conversion

 Key Features

1). Simplify to make a electric-scooter. Gearbox, transmission shaft, clutch are no need. Which save space.

2). It could be installed in the rear to save more space for battery.

3). Support regenerative braking

4). High efficiency: 85~92%

 Product Description

1. Genearlly Spec:

2. Dimension Drawing:

3. Test Report:

Test with ND72680 , DC Current 200A max , Phase Current 660A max

QSMOTOR QSD165B-35 Conversion Kits

QSMOTOR QSD165B-35 Conversion Kits

QSMOTOR QSD165B-35 Conversion Kits  Application

EV Your Life!

Additional information

Weight 17 kg
Dimensions 34 × 34 × 43 cm
